UC2526ADWTR
Manufacturer:
Texas Instruments
Mfr.Part #:
UC2526ADWTR
Datasheet:
Description:
Voltage Regulators - Switching SOIC-18 SMD/SMT Flyback, Push-Pull, Boost Transistor Driver 13 V
| Parameter | Value |
|---|---|
| Length | 11.5 mm |
| Width | 7.5 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Number of Pins | 18 |
| Height | 2.65 mm |
| Packaging | Reel |
| Thickness | 2.35 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Frequency | 450 kHz |
| Output Current | 100 mA |
| Output Voltage | 13 V |
| Output Type | Transistor Driver |
| Max Supply Voltage | 35 V |
| Max Frequency | 550 kHz |
| Topology | Flyback, Push-Pull, Boost |
| Switching Frequency | 550 kHz |
| Number of Outputs | 2 |
| Fall Time | 100 ns |
| Rise Time | 300 ns |
| Nominal Input Voltage | 35 V |
| Duty Cycle | 49 % |
| Max Duty Cycle | 50 % |
| Schedule B | 8542390000 |
| Function | Step-Up, Step-Up/Step-Down |
